IKA Dispersers T 50 digital ULTRA-TURRAX Powerful dispersing instrument for volumes from 0.25 - 30 l (H2O) with digital speed display. It offers a wide speed range from 500 � 10,000 rpm that enables users to work at high circumferential speeds even with small rotor diameters. A broad choice of dispersing elements guarantees a wide range of applications. Reproducible operations due to constant speed even with changes in viscosities. � Digital speed display � Electronic speed control � Electronic overload protection � Stainless steel dispersing elements can be cleaned quickly and easily � Smooth start � Error code display Technical Specifications Motor rating input 1100 W Motor rating output 700 W Volume range min. (H2O) 0.25 l Volume range max. (H2O) 30 l Viscosity max. 5000 mPas Speed range 600 - 10000 rpm Speed deviation 1 % Speed control stepless Speed display LED Noise without element 72 dB(A) Extension arm diameter 16 mm Extension arm length 220 mm Process type batch Timer no Permissible ON time 100 % Dimensions (W x H x D) 115 x 355 x 139 mm Weight 5.76 kg Permissible ambient temperature 5 - 40 �C Permissible relative humidity 80 % Protection class according to DIN EN 60529 IP 20 RS 232 interface no USB interface no Analog output no Voltage 220 - 240 / 100 - 120 V Frequency 50/60 Hz Power input 1100 W

IKA Dispersers T 50 digital ULTRA-TURRAX
